USED HAAS GM-2 AX FIVE-AXIS GANTRY MACHINING CENTER

The HAAS GM-2 AX gantry machining center is a used five-axis machine designed for milling applications. advanced. With an X-axis travel of 3,683 mm, Y of 2,223 mm and Z of 998 mm, it offers remarkable machining capacity large workpieces. The B and C axes have a wide range of inclinations and speeds, allowing for a superior operating flexibility, respectively 120° and 245°, with maximum speeds of 110°/s and 200°/s. The machine is equipped with a spindle with a power of 12 kW, capable of reaching 20,000 rpm, and with a torque maximum of 15.3 Nm at 7,500 Rpm. The HSK-A63 tool holder and a tool magazine with a capacity of 30+1 places promote fast and efficient tool changes. The table measures 3,658 mm long by 1,829 mm wide, with the ability to support up to 6,000 lbs of evenly distributed load. Other features include rapid feeds on the X, Y and Z axes of 12, 48 and 30 m/min respectively, and a SMTC automatic tool change system. The machine has a total weight of 10,000 kg and dimensions of 6,127 x 4,014 x 4,089 mm. With a high cooling capacity of 360 liters, the GM-2 AX is ideal for intensive production environments, offering precision and reliability in the machining of complex components.
